Timing Belt Pulleys 3mm Pitch GT Series Single Flange

Timing Belt Pulleys 3mm Pitch GT Series Single Flange
  • G = No. of Grooves
  • B = Bore +.001
  • OD = Outside Diameter
  • FD = Flange Diameter +/-1/64
  • F = Face Width
  • HD = Hub Diameter +/-1/64
  • L = Length +/-1/64
  • SS = Screw Size
  • PD = Pitch Dia.
Material: Aluminum Alloy. 2 set screws at 9 degrees apart.
  • G = No. of Grooves
  • B = Bore +.001
  • OD = Outside Diameter
  • FD = Flange Diameter +/-1/64
  • F = Face Width
  • HD = Hub Diameter +/-1/64
  • L = Length +/-1/64
  • SS = Screw Size
  • PD = Pitch Dia.
Part No. of Grooves Bore +.001 Outside Diameter Flange Diameter +/-1/64 Face Width Hub Diameter +/-1/64 Length +/-1/64 Screw Size Pitch Dia.
Buy View .18800 .63700 .92700 #6-40
FNA-F4-16 16 .188 .572 .710 .637 .710 .927 #6-40 .602
FNA-F4-17 17 .188 .609 .740 .637 .740 .927 #6-40 .639
